Increment |
Propelling Composition |
Web size (in) approx. |
Weight (lbs) approx. |
3 | M1, SP | 0.33 | 4.0 |
4 | M1, SP | 0.33 | 1.2 |
5 | M1, SP | 0.33 | 1.7 |
6 | M1, SP | 0.33 | 2.8 |
7 | M1, SP | 0.33 | 3.4 |
Technical data: | |
Type | White bag, separate loading |
Weight | 6.35 kg |
Length | 53.34 cm |
Colour | White with black markings |
Propellant | M1 (6.08kg explosive) |
Cannon used with | M1, M1A1, M45, M126, M126A1, M185, M199 |
Technical data: | |||
Temperature Limits | Firing | Lower limit | -40 °F (-40 °C) |
Upper limit | +125 °F (+51 °C) | ||
Storage | Lower limit | -80 °F ( -62 °C) (for periods not more than 3 days) | |
Upper limit | +140 °F (+60 °C) (for periods not more than 4 hrs/day) | ||
Packing | One (1 ) M4A2 propelling charge is packed in one (1) metal container. Twenty eight (28 ) metal containers M13A2 packed in one (1) wooden palette. |
